RANGER R 115 FD 85 CHEM

Cod: 10.0815.01

RANGER R 115 FD 85 CHEM

Overview

Ranger R 115 FD 85 is the ride-on scrubber dryer designed for cleaning operations in medium and large areas. It combines high performance and ergonomics along with maximum comfort for the operator. 115 liter capacity and the large cleaning width (850 mm) ensure a productivity of 5000 m²/h. The extra down pressure and detergent action (chemical mixing system) ensure excellent cleaning performance; the sturdy aluminium brush head is able to perfectly adapt itself to any obstacle and makes Ranger the ideal machine for cleaning closed to wall. The squeegee, with natural rubber blades supplied as standard, guarantees the best drying performance on every kind of surface. In the event of accidental impacts, the squeegee can also move and automatically retract under the machine frame, guaranteeing maximum safety and effectiveness. The practical and intuitive control panel ensures the control and management of all the machine functions: - it is possible to be immediately ready for the work session thanks the READY TO GO function which allows, by pressing a single button, the activation and setting of all the main functions of the machine; - the ECO SYSTEM program optimizes consumptions and eliminates waste, making Ranger an eco-friendly machine. Ranger is easy to use, no training is required and even daily maintenance operations are quick and easy. That is why even the untrained operators are able to work with this professional scrubber dryer. Available in three versions, one basic and two full package (BC and BC PLUS), with batteries and battery charger included, Ranger can reach up to 7 hours running time in the BC PLUS version!

RANGER R 115 FD 85 CHEM

Technical data

FEATURES

  • Cleaning widthmm850
  • Squeegee widthmm1050
  • Productivity (theor./practical)m²/h5000 - 3000
  • Power supplyBattery 24 V
  • Installed powerW2300
  • Advancementwith traction
  • IP codeIPX3

BATTERIES

  • Type---
  • Running timeh - min---
  • Battery compartment dimensions x Nomm x No380x625x440 X 1

BRUSHES

  • Pad diameter x Nomm - inch x nr 430 - 17" x 2
  • Motor rating x NoW x nr500 x 2
  • Motor speedrpm165
  • Down pressure - Contact pressureKg - g /cm²37;72 - 17;34

TRACTION

  • Motor ratingW 600
  • Driving speedKm/h6
  • Hill climbing ability%2

VACUUM

  • Motor ratingW550
  • Vacuummbar - mmH2O125 - 1250
  • Airflow ratingl/s30
  • Noise leveldB(A)67/59 (silent mode)

TANK

  • TypeDouble tank
  • Cleaning solution tankl110
  • Recovery tankl115
  • Weight (empty - with batteries)Kg246 / ---
  • Dimensionsmm1470x1055x1365

RANGER R 115 FD 85 CHEM

Standard accessories

  • 30.0024.00SOLUTION TANK FILLING HOSE
  • 40.0002.0017" POLYPROPYLENE BRUSH Ø 0,7
  • 22.0714.00GR.PARASPRUZZI TESTATA 850 UAB
  • 96.0178.00SET NATURAL RUBBER SQUEEGEE BLADES (FRONT/REAR)
  • 96.0179.00CHEMICAL MIXING SYSTEM

Optional accessories

  • 40.0102.0017" POLYPROPYLENE BRUSH Ø 0.9
  • 40.0202.0017" TYNEX BRUSH Ø 1.2 GRIT 80
  • 40.1007.00PAD HOLDER 420 MM (FOR 17" PAD)
  • 96.0178.01SET POLYURETHANE SQUEEGEE BLADES (FRONT/REAR)
  • 96.0180.00HEADLIGHT KIT
  • 96.0181.00BLINKING KIT
  • 96.0182.00CORNER DRYING KIT
  • 96.0183.00WATER STOP KIT
